BESEN PCD030 Portable EV Charger
High-Quality Style, 5 Adjustable Current
- Maximum Power: 3.6KW
- Certificate: CE/TUV/RoHS/REACH
- RCD Type: Type A / Type A+6mA DC
- Waterproof Rating: IP67
- Impact Protection: IK10
- Weight: 3kg
- External Dimension: 249/105/55 mm
- ODM&OEM Available
BESEN PCD030 Portable EV Charger Overview
The BESEN PCD030 Portable EV Charger is a versatile and user-friendly charging solution designed for electric vehicle (EV) owners seeking reliable and efficient charging at home, work, or on the go.
Key Features:
-
-
Adjustable Charging Current: The PCD030 allows users to switch between 6A and 16A charging currents, with a maximum power output of 3.6kW. This adjustability enables customization of charging speed to align with specific requirements and electrical system capacities.
-
LCD Display: Equipped with a color LCD screen, the charger provides real-time information on charging status, including current settings, power output, and temperature, facilitating informed monitoring and control.
-
Comprehensive Safety Protections: The PCD030 incorporates multiple safety mechanisms, such as under-voltage protection, overload protection, short circuit protection, earth leakage protection, over-temperature protection, and lightning protection, ensuring secure operation under various conditions.
-
Durable and Weather-Resistant Design: With an IP67 rating for waterproofing and an IK10 rating for impact resistance, the charger is built to withstand harsh environments, making it suitable for both indoor and outdoor use.
-
Universal Compatibility: The PCD030 offers various connector types, including SAE J1772, IEC 62196-2, and GB/T, along with plug options such as Schuko, UK, CEE, NEMA, and AU, ensuring compatibility with a wide range of EVs and regional power outlets.
-
Why Choose BESEN PCD030?
The BESEN PCD030 Portable EV Charger is designed to provide a flexible, safe, and efficient charging experience for EV owners. Its adjustable current settings and clear LCD display allow users to tailor the charging process to their specific requirements, while the comprehensive safety features and durable construction ensure reliability and peace of mind. Whether at home, the workplace, or during travel, the PCD030 offers a dependable charging solution.
BESEN PCD030 Portable Charger Design
- Parameters
- Video
- Gallery
| Specification | PCD030 | |
| Connector and Electrical | Input Voltage / Output Voltage | 100~250V AC |
| Input Frequency | 47~63Hz | |
| AC Power Output Rating | 3.6kW | |
| Max. Output Current | 16A 1 phase | |
| Terminal Connection | Schuko / UK / CEE / NEMA / AU | |
| Connector Type | SAE J1772, IEC 62196-2, GB/T | |
| Performance and Safety | Ingress Protection | IP67 |
| Impact Protection | IK10 | |
| Electrical Protection | Under Voltage Protection / Over Load Protection / Short Circuit Protection / Leakage Protection / Over-temp Protection /Lightning Protection | |
| RCD Type | Type A / Type A+6mA DC | |
| Environment Temperature | -25°C~55°C | |
| Certifications | CE/TUV/RoHS/REACH | |
| Function | Current Adjusting | Yes |
| Ethernet/WIFI/4G/Bluetooth | No | |
| LED Indicator Light | Yes | |
| LCD Display Screen | Yes | |
| LCD Touch Screen | No | |
| Time Setting | No | |
| Time Delay Setting | No | |
| App Control | No | |
| Mechanical | Dimension(L/W/D) | 249/105/55 mm |
| Weight | 3kg | |
BESEN 3.6kW Portable Electric Car Charger Solution
2-5 Adjustable Current Output
✅Supports 2-5 adjustable current levels, with a default 10A/16A setting. Can be factory-set to a fixed current or customized for other amperages (MOQ required).
Smart LCD Display for Real-Time Monitoring
✅Shows charging status, current, voltage, temperature, and fault alerts, providing a clear and user-friendly experience.
Complete Certification
✅The product has passed all relevant certifications in Europe and North America to ensure that the product is sold and used confidently.
Portable & Easy to Use for Various Scenarios
✅Compact and lightweight, perfect for home use, travel, and emergency charging. Plug-and-play design, no installation required.
Why Choose BESEN PCD030 Portable Electric Car Charger?
BESEN PCD030 Portable EV Charger Features
- LCD Display
- LED Light Indicator
- Touch-Sensitive Button
Smart LCD Display for Real-Time Monitoring
- Displays real-time voltage, charging amount (kWh), charging duration, working temperature, and real-time current.
- Fault detection system with error reporting, such as leakage protection warnings.
- Easy-to-read interface for a clear and efficient charging experience.
LED Status Indicator for Charging Phases
- Idle: LED is off.
- Connected: Continuous green light.
- Charging: Rolling green light.
- Charging Completed: Continuous green light.
- Error: Flashing red light.
- The LED display provides instant status updates, helping users quickly identify the charging state and any potential issues.
Adjustable Charging Current (10A/16A) with One-Button Control
- Users can switch between 10A and 16A by pressing the button on the charger (only for the current-switchable version).
- Enables flexibility in charging speed depending on power availability.
- Ideal for different home and travel charging scenarios.
PCD030 Portable EV Charger ODM & OEM Options (8)
-
-
-
5m (default configuration) – Wall-end: 1.5m, Car-end: 4m, Available upon request to fit specific user needs.
-
-
-
- TPE (Thermoplastic Elastomer) – Flexible, lightweight, and cost-effective.
- TPU (Thermoplastic Polyurethane) – More durable, resistant to wear, and has superior cold resistance.
-
- Type 1 (SAE J1772) – Standard for North America.
- Type 2 (IEC 62196-2) – Standard for Europe.
- GB/T – Standard for China.
-
- Schuko Plug – Standard in Europe.
- UK Plug – British Standard.
- CEE Plug – Industrial and commercial use.
- NEMA Plug – North American standard (e.g., NEMA 5-15P, NEMA 14-50).
- AU Plug – Australian standard.
Unlock BESEN PCD030 Exclusive Pricing
Partner with BESEN
BESEN invites global partners to collaborate in distributing our PCD030 Portable EV Charger. We seek distributors, retailers, and industry experts to expand our market reach and provide EV users with high-quality charging solutions. Partners will benefit from our technical support, marketing resources, and competitive collaboration policies.
BESEN AC Portable Electric Car Charger Series (8)
Yes! The PCD030 works with most EVs and PHEVs, supporting Type 1 (SAE J1772), Type 2 (IEC 62196-2), and GB/T connectors. It can be used with various power plug types, making it an ideal portable car charger for electric cars in multiple regions.
The PCD030 EV travel charger offers a 3.6kW charging capacity with a maximum output of 16A (single-phase). It supports adjustable charging currents (10A/16A) for flexibility based on power availability.
Absolutely! The PCD030 is a perfect EV travel charger, designed for on-the-go charging. Its compact size, lightweight design, and multi-plug compatibility make it easy to carry in your car for road trips, vacations, or emergency charging needs.
The PCD030 supports multiple power plug types, ensuring compatibility with global power outlets, including:
✅ Schuko Plug (Europe)
✅ UK Plug (British Standard)
✅ CEE Plug (Industrial Use)
✅ NEMA Plug (North America)
✅ AU Plug (Australia)
The PCD030’s standard cable length is 5 meters (1.5m wall-end + 4m vehicle-end). For e-commerce versions, a 6-meter length (1.5m + 4.5m) is commonly used. Custom cable lengths are available upon request.
Yes! BESEN offers OEM & ODM customization, including:
✅ Custom branding (stickers & laser engraving)
✅ Cable customization (length, color, coiled/straight, TPE or TPU material)
✅ Plug customization (Type 1, Type 2, GB/T, and multiple wall-end plug options)
The PCD030 provides 3.6kW charging power, delivering up to 16A of current. The exact charging speed depends on your EV’s battery capacity and onboard charger. Typically, it can charge an EV from 20% to 80% in a few hours, making it an excellent portable charger for electric cars.
No, the PCD030 Portable EV Charger does not support time delay charging. It is a plug-and-play charger, meaning it starts charging immediately when plugged into a power source and connected to the vehicle.
However, if you require a portable EV charger with time delay functionality, consider the BESEN PCD032 model, which includes a time delay setting for more flexible charging schedules.
