What is J1772 Charger？
A J1772 charger, also known as a Type 1 charger, refers to an electric vehicle (EV) charging station that uses the SAE J1772 standard connector. This standard is predominantly used in North America and is compatible with most electric vehicles and plug-in hybrids in the region.
Connector Design: It has a five-pin configuration which includes two pins for power, one for grounding, and two for communication between the charger and the vehicle. This setup ensures that charging does not start until the connector is properly engaged.
Safety Features: The J1772 connector includes a locking mechanism to prevent it from being accidentally disconnected during charging. It also ensures that electricity flows only when the connector is securely attached, enhancing safety.
Charging Levels:
Level 1 Charging: Utilizes a standard 120V outlet, typically offering a slower charging speed ideal for overnight use.
Level 2 Charging: Uses a 240V supply, providing faster charging speeds and is the most common application for the J1772 charger.
Usage: The J1772 charger is widely used across public charging stations and home chargers, making it a versatile option for EV drivers.
J1772 EV Charger OEM Manufacturer
BESEN is the leading OEM manufacturer in the J1772 charger field and is committed to providing the safest, most efficient, and reliable AC electric vehicle charging for home and commercial users.
Why Choose J1772 Chargers for Your Business?
Standardization: J1772 is the standard connector type in North America, ensuring wide compatibility.
Reliability: Known for their robust construction and longevity.
Cost-Effective: Offers a balance between cost and performance, making it an economical choice for mass deployment.
J1772 EV Chargers BESEN Offer You
BESEN is a leading manufacturer specializing in the development and production of J1772 EV Chargers, our commitment to quality has made us the top supplier of J1772 EV charging solutions worldwide.
Our SAE j1772 chargers include two different series, namely J1772 EV Charging Stations and J1772 Portable EV Chargers.
J1772 EV Charging Stations Manufacturer in China
- J1772 EV Charging Stations Data Sheet
- J1772 Portable EV Chargers Data Sheet
- Certification & Patent
| Specification | BS20 | BN30 | |
| Connector and Electrical | Input Voltage / Output Voltage | AC 230V/400V | AC 230V/400V |
| Input Frequency | 47~63Hz | 47~63Hz | |
| AC Power Output Rating | 3.6kW / 7.2kW /11kW / 22kW | 3.6kW / 7.2kW /11kW / 22kW | |
| Max. Output Current | 32A | 32A | |
| Connector Type | SAE J1772 | SAE J1772 | |
| Performance and Safety | Ingress Protection | IP66 | IP66 |
| Impact Protection | IK10 | IK10 | |
| Electrical Protection | Under Voltage Protection / Over Load Protection / Short Circuit Protection / Earth Leakage Protection / Over-temp Protection /Lightning Protection | ||
| RCD Type | Type A / Type A+6mA DC | Type A / Type A+6mA DC | |
| Environment Temperature | -25°C~55°C | -25°C~55°C | |
| Certifications | CE/FCC/CSA/RoHS/ETL/REACH | CE/RoHS | |
| Function | Current Adjusting | Yes | Yes |
| Ethernet/WIFI/4G/Bluetooth | Optional | Optional | |
| LED Indicator Light | Yes | Yes | |
| LCD Display Screen | 3.5-inch Color Display | No | |
| Mounting Method | Wall-Mounted / Ground-mounting Pole | ||
| Basic | Yes | Yes | |
| App | Yes | Yes | |
| Rfid | Yes | Yes | |
| Dynamic Load Balancing | Yes | No | |
| Ocpp | Yes | No | |
| Mechanical | Dimension(L/W/D) | 295/195/65mm | 120/100/280mm |
| Weight | 6kg~8kg | ||
| Specification | PCD020 | PCD030 | PCD032 | PCD040 | BN20 | |
| Connector and Electrical | Input Voltage / Output Voltage | 100~250V AC | 100~250V AC | 100~250V AC | 100~250V AC | 100~250V AC |
| Input Frequency | 47~63Hz | 47~63Hz | 47~63Hz | 47~63Hz | 47~63Hz | |
| AC Power Output Rating | 3.6kW | 3.6kW | 3.6kW | 8.8kW | 3.6kW | |
| Max. Output Current | 16A 1 phase | 16A 1 phase | 16A 1 phase | 40A 1 phase | 16A 1 phase | |
| Terminal Connection | Schuko / UK / CEE / NEMA / AU | Schuko / UK / CEE / NEMA / AU | Schuko / UK / CEE / NEMA / AU | CEE / NEMA 14-50 / NEMA 6-50 | Schuko / UK / CEE / NEMA / AU | |
| Connector Type | SAE J1772 | |||||
| Performance and Safety | Ingress Protection | IP66 | IP66 | IP66 | IP66 | IP66 |
| Impact Protection | IK10 | IK10 | IK10 | IK10 | IK10 | |
| Electrical Protection | Under Voltage Protection / Over Load Protection / Short Circuit Protection / Earth Leakage Protection / Over-temp Protection /Lightning Protection | |||||
| RCD Type | Type A / Type A+6mA DC | Type A / Type A+6mA DC | Type A / Type A+6mA DC | Type A / Type A+6mA DC | Type A / Type A+6mA DC | |
| Environment Temperature | -25°C~55°C | -25°C~55°C | -25°C~55°C | -25°C~55°C | -25°C~55°C | |
| Certifications | CE/RoHS | CE/TUV/RoHS | CE/RoHS | CE/RoHS/FCC | CE | |
| Function | Current Adjusting | Yes | Yes | Yes | Yes | Yes |
| Ethernet/WIFI/4G/Bluetooth | No | No | No | No | No | |
| LED Indicator Light | Yes | Yes | Yes | Yes | Yes | |
| LCD Display Screen | No | Yes | Yes | Yes | No | |
| LCD Touch Screen | No | No | No | No | No | |
| Time Setting | No | No | Yes | No | No | |
| Time Delay Setting | No | No | Yes | No | No | |
| Mechnical | Dimension(L/W/D) | 245/105/48 mm | 249/105/55 mm | 249/104/48 mm | 265/105/55 mm | 189/66/48 mm |
| Weight | 2.5kg | 3kg | 3.5kg | 5kg | 3kg | |
Send Inquiry
What solutions are there?
BESEN is a leading OEM manufacturer of J1772 EV chargers, known for providing reliable and efficient charging solutions. In recent years, the competition in the EV charging market has become particularly fierce, with various low-cost, inferior products flooding the market. BESEN stands out by continually improving product quality while reducing costs, making us the top choice for distributors entering the EV charging industry. Our chargers combine the latest technology and innovative design to meet various needs.
Ready to Upgrade Your Inventory? Boost Your Business with BESEN’s J1772 Chargers
Are you looking to enhance your product offerings with reliable and efficient EV charging solutions? BESEN’s J1772 chargers are the perfect addition to your inventory. As a wholesaler, partnering with BESEN ensures you get top-quality products that meet the demands of your customers.
Fill out the form to request more information or to place a wholesale order. Our team is ready to assist you and provide the support you need to grow your business.
While J1772 chargers are considered fast charging, they are not ultra-fast chargers in the same manner as the Tesla Superchargers. The J1772 is typically used for Level 2 charging and provides medium-level power suitable for at-home charging and a wide range of other public charging solutions. The combination of speed and convenience allows these chargers to be used in a lot of different applications.
A vehicle with a Type 1 inlet will be directly compatible with a J1772 charger. This applies to most electric vehicles that are sold in North America, with the J1772 connector being the standard. On the other hand, vehicles sold in Europe with a Type 2 inlet will need an adaptor to work with a J1772 charger. For example, Tesla vehicles can make use of J1772 chargers with the correct adapter.
The CCS (Combined Charging System) connector is essentially an SAE J1772 charging inlet, but with two more pins added to the bottom. It is aptly named because it “combines” the SAE J1772 connector with the high-speed charging pins. This design allows for flexibility in charging, such as AC and DC fast charging.
No, Type 2 is not the same as J1772. Type 2, sometimes called Mennekes, is the European standard and conforms to the IEC 62196 protocol. Its design is such that it will accept single-phase and three-phase charging; therefore, it is more flexible in terms of power delivery. J1772 standards are a North American standard at Level 1 and 2 charging. The two services different markets and have different regulatory protocols.
Yes, a J1772 can use a Tesla charger with the appropriate adapter. Tesla makes a J1772 adapter for non-Tesla EVs to connect to Tesla charging stations. To be more specific, this adapter has now expanded the application options for vehicles compatible with this type of outlet by providing them access to the huge Tesla Supercharger network, bringing convenience and flexibility to EV users.
